TP-LINK VIGI C540S(4mm) 4MP Outdoor ColorPro Night Vision Pan Tilt Network Camera
TP-LINK VIGI C540S(4mm) 4MP Outdoor ColorPro Night Vision Pan Tilt Network Camera - Image 2
TP-LINK VIGI C540S(4mm) 4MP Outdoor ColorPro Night Vision Pan Tilt Network Camera - Image 3
TP-LINK VIGI C540S(4mm) 4MP Outdoor ColorPro Night Vision Pan Tilt Network Camera - Image 4

TP-LINK VIGI C540S(4mm) 4MP Outdoor ColorPro Night Vision Pan Tilt Network Camera

  • Ultra-Low Light Color Night Vision
  • 360° Monitoring
  • People & Vehicle Analytics
  • Human & Vehicle Classification
  • Smart Detection
  • True WDR Technology§
  • Active Defense
  • Two-Way Audio
  • H.265+
  • IP66 Waterproof

฿4,990.00*ราคายังไม่รวม VAT
฿5,339.30*ราคารวม VAT แล้ว

ขอใบเสนอราคา
CAMERA
Image Sensor1/1.79” Progressive Scan CMOS
Shutter Speed1/3 to 1/10000 s
Slow ShutterYes
Minimum Illumination0.0005 Lux; 0 Lux with White Light
Day/Night MechanismN/A
Day/Night SwitchUnified/Scheduled/Auto
LENS
TypeFixed Focal Lens
Focal Length4 mm
ApertureF1.0±5%
FOV4mm:
Horizontal FOV: 104°, Vertical FOV: 55°, Diagonal FOV: 127°
Lens MountM16*P 0.5
DORI Distance4 mm:
Detect: 63 m (207 ft)
Observe: 26 m (86 ft)
Recognize: 13m (41 ft)
Identify: 6 m (21 ft)
PTZ
Pan/tilt RangePan: 0° to 348°, Tilt: 0° to 105°
Pan/tilt SpeedPan Speed:
Configurable from 8° to 44°/s; Preset Speed: 44°/s

Tilt Speed:
Configurable from 8° to 44°/s, Preset Speed: 44°/s

Manual Control SpeedConfigurable from 8° to 35°/s
Presets300
Patrol Scan8 patrols, up to 8 presets for each patrol
Power-off MemoryYes;
Auto restore to previous PT and lens status after power failure
Park ActionYes;
Preset; Patrol Scan
3D PositioningYes
Angle Adjustment (Manual)
RangePan: 0° to 348°
Tilt: 0° to 105°
ILLUMINATOR
IR LEDN/A
White LEDQuantity: 2
Range: 30m
Illuminator On/Off ControlAuto/Scheduled/Always on/Always off
VIDEO
Max. Resolution2688 x 1520
Main StreamFrame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
2688×1520, 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720

Sub-StreamFrame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Resolution:
704×576, 640×480, 352×288, 320×240

Bit Rate ControlCBR, VBR
Video CompressionMain Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
H.264 TypeHigh Profile
H.264+Main Stream Supported
H.265 TypeMain Profile
H.265+Main Stream Supported
Video Bit RateMain Stream: 256 Kbps to 6 Mbps
Sub-Stream: 64 Kbps to 512 Kbps
Image SettingsMirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR,
White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image EnhancementBLC/3D DNR/HLC
Wide Dynamic Range120dB
SNR≥ 52 dB
Image Parameters SwitchYes
Privacy MaskUp to 4 Masks
ROI1 Region
OSD SettingYes
AUDIO
Audio CommunicationTwo-Way Audio
Audio InputYes
Audio OutputYes
Audio CompressionYes
Audio Sampling Rate8KHz
Environment Noise FilteringYes
Audio Bit Rate64 Kbps(G.711 alaw)
NETWORK
Protocol• TCP/IP
• UDP
• ICMP
• HTTP
• HTTPS
• DHCP
• DNS
• RTSP
• NTP
• UPnP UDP
• SSL/TLS
• FTP/SFTP
• RTP
• IPv4
• IPv6
• ARP
• SMTP
• SNMP
• IEEE 802.1x
ONVIFYes
APIOpen Network Video Interface (Profile S)
Simultaneous Live View3 Main Streams & 3 Sub-Streams
ClientVIGI App, VIGI Security Manager, Web UI
Web BrowserGoogle Chrome® 57 and above
Firefox® 52 and above
Safari® 11 and above
Microsoft® Edge 91 and above
CloudYes
SecurityPassword Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
ALARM AND EVENT MANAGEMENT
Smart EventHuman & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, People Detection, Vehicle Detection, Abnormal Sound Detection, Scene Change Detection
Basic EventMotion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm LinkageMemory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage MethodN/A
Output NotificationMessage Push
Deep Learning Function
People & Vehicle AnalyticsSearch and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier*.
INTERFACES
Network Interface1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
AlarmN/A
Reset ButtonYes
PowerDC Power Port
On-board StorageBuilt-In Memory Card Slot, Support MicroSD Card, Up to 512 GB†
Built-in MicrophoneYes; Records Anything Going on within a 15-ft Radius of the Camera
Built-in SpeakerYes
AudioN/A
GENERAL
Operating Temperature-30–60 °C
Storage Temperature-40–60 °C
Operating Humidity95% or Less (Non-Condensing)
Storage Humidity95% or Less (Non-Condensing)
Package ContentVIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories
MaterialPlastic
Power Supply12V DC ± 5%, Max. 13.13 W, 5.5mm Coaxial Power Plug
PoE: 802.3at, class 4, Max. 16.47 W
ProtectionIP66
Product Dimensions (L x W x H)120 × 172 × 203 mm
CertificationsCE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
รหัสสินค้า: VIGI C540S(4mm) หมวดหมู่:
