Synology DiskStation DS923 Plus
Synology DiskStation DS923 Plus - Image 2
Synology DiskStation DS923 Plus - Image 3
Synology DiskStation DS923 Plus - Image 4
Synology DiskStation DS923 Plus - Image 5
Synology DiskStation DS923 Plus - Image 6

Synology DiskStation DS923 Plus

  • 4-bay DiskStation (up to 9-bay),
  • AMD Ryzen R1600 (Dual-Core/ 2.6 GHz (turbo to 3.1 GHz)),
  • 4GB DDR4 ECC SODIMM (Max. 32GB),
  • 2 x M.2 NVMe SSD,
  • 2x1GbE Base T,
  • 1 x 10GbE RJ-45 (Optional),
  • ประกันสินค้า 3 ปี RMA (ต่อประกันเพิ่มได้เป็น 5 ปี(SNG-EW201))

฿22,900.00*ราคายังไม่รวม VAT
฿24,503.00*ราคารวม VAT แล้ว

ขอใบเสนอราคา

คุณสมบัติ

Hardware
CPUAMD Ryzen™ R1600 dual-core (4-thread), max. boost clock up to 3.1 GHz
Hardware encryption engineAES-NI
Memory4 GB DDR4 ECC SODIMM (expandable up to 32 GB)
Compatible drive types• 4 x 3.5″ or 2.5″ SATA HDD/SSD (drives not included)
• 2 x M.2 2280 NVMe SSD (drives not included)
• Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list
Hot swappable drivesYes
External ports• 2 x USB 3.2 Gen 1 ports
• 1 x Expansion port (eSATA)
Form factorDesktop
Size (HxWxD)166 x 199 x 223 mm
Weight2.24 kg
LAN ports2 x 1GbE RJ-45
Wake on LAN/WANYes
Network expansionSupports E10G22-T1-Mini 10GbE RJ-45 Network Upgrade Module
Scheduled power on/offYes
System fans2 x (92 x 92 x 25 mm)
AC input power voltage100 V to 240 V AC
Power frequency50/60 Hz, single phase
Operating environment• Temperature: 0°C to 40°C (32°F to 104°F)
• Relative humidity: 8% to 80% RH
Storage environment• Temperature: -20°C to 60°C (-5°F to 140°F)
• Relative humidity: 5% to 95% RH
Maximum operating altitude5,000 m (16,400 ft)
General DSM Specifications
Networking protocolsSMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN™, L2TP)
File systems• Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT
Supported RAID typesSynology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10
Storage management• Max. single volume size: 108 TB
• Max. number of system snapshots: 65,536
• Max. number of internal volumes: 64
SSD cache• Read/write cache support
• M.2 NVMe and 2.5″ SATA SSD support
File sharing capabilities• Max. number of local user accounts: 2,048
• Max. number of local groups: 256
• Max. number of shared folders: 512
• Max. number of concurrent SMB/NFS/AFP/FTP connections: 1,000
PrivilegesWindows® Access Control List (ACL) and application privileges
Directory servicesConnects with Windows® AD/LDAP servers enabling domain users to login via SMB/NFS/AFP/FTP/File Station using their existing credentials
VirtualizationVMware vSphere®, Microsoft Hyper-V®, Citrix®, OpenStack, and Kubernetes
SecurityFirewall, shared folder encryption, SMB encryption, FTP over SSL/TLS, SFTP, rsync over SSH, login auto block, Let’s Encrypt support, and HTTPS (customizable cipher suite)
Supported browsersGoogle Chrome®, Firefox®, Microsoft Edge®, Safari® 13 and later, and Safari (iOS 13.0 and later) on iPad, Chrome (Android™ 11.0 and later) on tablets
Packages and Applications
File Server & Synchronization
DriveSynchronizes files across Windows®, macOS®, Linux®, Android™, and iOS. The built-in cross-platform portal allows access to data anytime and anywhere
• Max. number of hosted files: 5,000,000
• Max. number of concurrent connections for PC clients: 350
File StationProvides virtual drives, remote folders, Windows® ACL editor, compression/extraction of archived files, bandwidth control for specific users/groups, creation of sharing links, and transfer logs.
Hybrid ShareEfficiently synchronizes files across sites by keeping shared data on Synology C2 Storage and streaming files to Synology NAS worldwide on request. Frequently requested files are cached at each site for low-latency access.
FTP ServerSupports bandwidth control for TCP connections, custom FTP passive port ranges, anonymous FTP, FTP over TLS/SSL and SFTP protocols, network booting with TFTP and PXE support, and transfer logs.
Presto File ServerEnables high-speed data transfer over WAN between Synology NAS and desktop platforms through the exclusive SITA technology.
Cloud SyncOffers one or two-way synchronization with public cloud storage providers including Alibaba Cloud OSS, Backblaze B2, Baidu Cloud, Box, Dropbox, Google Cloud Storage, Google Drive, hubiC, MegaDisk, Microsoft OneDrive, OpenStack Swift-compatible storage, Tencent COS, WebDAV servers, and Yandex Disk.
Universal SearchSearch through files, metadata, and more on your NAS. Integration with Windows Search and macOS Spotlight makes it easy to find files.
Migration AssistantMigrates data, system setting, and applications seamlessly from one Synology NAS to another to ensure maximum service availability.
SAN Storage & Virtualization
SAN Manager• Max. number of iSCSI targets: 128
• Max. number of LUNs: 256
• LUN clone/snapshot support
Virtual Machine ManagerSupports running Windows®, Linux®, and Virtual DSM-based virtual machines on Synology NAS.
Data Protection & Backup Solutions
Hyper BackupSupports local backup, network backup, and data backup Synology servers, other devices, and public clouds, including C2 Storage
Backup tools• DSM configuration backup, macOS® Time Machine® support, Synology Drive Client desktop application
• Shared folder sync supports a maximum of 32 tasks
Snapshot Replication• Max. number of snapshots for shared folders: 1,024
• Max. number of replications: 32
Synology High AvailabilityReduces service downtime by combining two identical NAS into a high-availability cluster.
Active Backup for BusinessAn all-in-one backup solution designed for heterogeneous business IT environments. It enables IT admins to remotely manage and protect PCs, servers, Synology systems, and VMs from one centralized console.
Active Backup for Google WorkspaceSupports backup and restoration of Google Workspace My Drive, Team Drive, Gmail, Contacts, and Calendar.
Active Backup for Microsoft 365Supports backup and restoration of Microsoft 365 OneDrive for Business, Outlook, Contacts, and Calendar.
Productivity & Collaboration
Collaboration toolsCollaborate with instant messaging service Synology Chat, online documents editor Synology Office, and scheduling assistant Synology Calendar
• Max. number of concurrent users for Chat: 100
• Max. number of users for Office: 1,200
• Calendar supports CalDAV and access via mobile device
Note StationA note taking platform that supports rich text, note organization and versioning, encryption, sharing, media embedding, and attachments
Synology MailPlus ServerA secure, reliable, and private mail solution featuring high-availability, load balancing, security, and filtering options
Synology MailPlusAn intuitive webmail interface for Synology MailPlus Server with configurable mail labels, filters, and user interface
Multimedia
Synology PhotosAn efficient photo management solution for professional and amateur photographers. Automated tools allow users to group, filter, organize, and share content while keeping their photos safe and secure.
Other packagesVideo Station, Audio Station, and iTunes® Server
Surveillance
Surveillance StationMax. number of IP cameras: 40, for a total of 1,200 FPS at 720p (H.264).
Management & Administration
Synology Directory ServerProvides a flexible and cost-effective domain controller solution.
Central Management SystemProvides a single interface to manage and monitor multiple Synology NAS.
VPN ServerMax. number of connections: 40. Supported VPN protocols: PPTP, OpenVPN™, L2DTP/IPSec.
Active InsightMonitor health statistics, login activity, and backup statuses for your Synology servers worldwide, and receive notifications and advice from our centralized cloud-hosted management platform.
Storage AnalyzerDisplays volume and quota usage, total size of files, volume usage and trends based on past usage, size of shared folders, large files, most recently modified files, and least recently accessed files.
Antivirus EssentialProvides full system scans, scheduled scans, white list customization, and auto-update of virus definitions.
Web StationEnables hosting for up to 30 websites with support for PHP/MariaDB® and 3rd-party applications.
Other packagesDNS Server, RADIUS Server, and Log Center
Others
iOS/Android™ applicationsSynology Drive, Synology MailPlus, Synology Secure SignIn, Synology Chat, Synology LiveCam, Synology Active Insight, DS cam, DS file, DS finder, and DS note.
Other packagesAdditional 3rd-party packages are available in the Package Center
Environment and Packaging
Environmental safetyRoHS compliant
Package contents• 1 x DS923+ main unit
• 1 x Quick Installation Guide
• 1 x Accessory pack
• 1 x AC power adapter
• 1 x AC power cord
• 2 x RJ-45 LAN cables
• DDR4 ECC SODIMM: D4ES02-4G / D4ES02-8G / D4ES01-16G
• Synology Network Upgrade Module: E10G22-T1-Mini
• M.2 2280 NVMe SSD: SNV3400 series
• 2.5″ SATA SSD: SAT5200 series
• 3.5″ SATA HDD: HAT5300 series
Optional accessories• Expansion Unit: DX517
• MailPlus License Pack
• Surveillance Device License Pack
• Virtual DSM License Pack
• Extended Warranty: EW201, Extended Warranty Plus
