HPE Aruba 6300F 48G CL4 PoE 4SFP56 Switch (48 x 1000Base-T PoE+ , 4 x 10/25/50G SFP56,740W)[JL665A]
HPE Aruba 6300F 48G CL4 PoE 4SFP56 Switch (48 x 1000Base-T PoE+ , 4 x 10/25/50G SFP56,740W)[JL665A] - Image 2
HPE Aruba 6300F 48G CL4 PoE 4SFP56 Switch (48 x 1000Base-T PoE+ , 4 x 10/25/50G SFP56,740W)[JL665A] - Image 3

HPE Aruba 6300F 48G CL4 PoE 4SFP56 Switch (48 x 1000Base-T PoE+ , 4 x 10/25/50G SFP56,740W)[JL665A]

  • Family of stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, OSPF robust security, QoS, MACsec 256, PTP, AVB and LRM1
  • The series includes three stackable Layer 2-only CX 6300L access switches with HPE Smart Rate Multi-Gigabit and MACsec 256 encryption.
  • High performance ASIC with 880 to 1760 Gbps system switching capacity, 660 to 1310 MPPS of system throughput and up to 200 to 400 Gbps stacking bandwidth.
  • Series includes options with full density HPE Smart Rate (1/2.5/5/10GbE) Multi-Gigabit, up to 90W PoE, and a switch bundle with power-to-port airflow for data center 1G ToR and OOBM deployments.
  • Built-in high speed 10/25/40/50/100 GbE uplinks with intelligent monitoring and visibility via the Network Analytics Engine.
  • Manage via single point of control with HPE Aruba Networking Central across wired, wireless, and WAN. Dynamic Segmentation enables enhanced security and simple access for users and IoT.

รบกวนติดต่อสอบถามก่อนสั่งซื้อ

฿399,000.00*ราคายังไม่รวม VAT
฿426,930.00*ราคารวม VAT แล้ว

ขอใบเสนอราคา

Power consumptionIdle: 63W
100% Traffic Rate: 86W

Input voltageFixed PSU: 100V‑120V/200V‑240V

Ports48-port 10/100/1000 BaseT PoE+ ports supporting up to 30W per port;

4x 1G/10G/25G/50G* SFP ports;

Supports PoE Standards IEEE 802.3af, 802.3at;

1x USB‑C Console Port;
1x OOBM port;
1x USB Type A Host port

Notes:
*50G capability is for use with 50G DACs for both interconnect and VSF stacking. 50G transceivers and DACs are not supported on S0E91A and S0X44A switch models, which requires QSFP to SFP56 DAC cable for VSF stacking with other CX 6300F and CX 6300M switch models only. VSF stacking not supported on 1G ports.

Latency1Gbps: 2.28μSec,
10Gbps: 1.46μSec,
25Gbps: 1.90μSec,
50Gbps: 3.49μSec

Switching capacity496 Gbps

Stacking capabilitiesUp to 10 switches per stack

NOTE: CX 6300L switches only stack with other CX 6300L switches

Throughput369 Mpps

Memory and processorQuad Core Arm Cortex™ A72 @ 1.8GHz
8 GB DDR4, 32 GB eMMC

8 MB, 16 MB, or 32 MB Shared Packet Buffer Memory, depending on model and configuration

PoE capabilityMax PoE Power: 740W

Management featuresHPE Aruba Networking Central Network Management
HPE Aruba Networking Management Software (AirWave)
HPE Aruba Networking Switch Multi-Edit Software
Command-line interface
SNMP v2c/v3
RMON

WarrantyLimited lifetime warranty. See the warranty duration.

Detailed product descriptionCX 6300F 48-port 1 GbE Class 4 PoE and 4-port SFP56 switch
Includes Non-Pluggable, Internal PSU behind Sheetmetal Chassis Frame
Includes Non-Pluggable, Internal Fans behind Sheetmetal Chassis Frame
Min=0 \ Max = 4 SFP/SFP+/SFP28/SFP56 1/10/25/50 G Transceiver
1U – Height

Weight5.10 kg (11.24 lbs)

Dimensions4.4 x 44.2 x 32.7 cm (1.73 x 17.4 x 12.9 in)

รหัสสินค้า: JL665A หมวดหมู่:
