| MECHANICAL | |
| Dimensions (L x W x H) | 62 x 169 x 82 mm (2.4″ x 6.6″ x 3.2″) |
| Weight | 130 g (4.6 oz) |
| ELECTRICAL | |
| Input Voltage | 4.0 to 5.5 VDC |
| Operating Power | 2.00 W (400 mA @ 5 VDC) |
| Standby Power | 0.45 W (90 mA @ 5 VDC) |
| Interface | USB |
| ENVIRONMENTAL | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Drop Resistance | 30 drops from 1.5 m (5 ft) to concrete |
| Environmental Sealing | IP42 |
| Light Levels | 0 to 100,000 lux |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Image (1280 x 800 pixel array) |
| Scan Angle | Horizontal: 47°; Vertical: 30° |
| Symbol Contrast | 35% minimum reflectance difference |
| Pitch, Skew | ±60°, ±70° |
| Decode Capability | All standard 1D, PDF417, and 2D symbologies (including high resolution) |
| WARRANTY | 3-year factory warranty |
