| MECHANICAL | |
| Scanner Dimensions (L x W x H) | 64 mm x 166 mm x 84 mm (2.5 in x 6.5 in x 3.3 in) |
| Charger/Communication Base Dimensions | 130 mm x 86 mm x 85 mm (5.1 in x 3.4 in x 3.3 in) |
| Scanner Weight | 190 g (6.7 oz) |
| Charger/Communication Base Weight | 150 g (5.29 oz) |
| ENVIRONMENTAL | |
| Operating Temperature – Scanner | Charging: 5°C to 40°C (41°F to 104°F) Non-Charging: -20°C to 50°C (-4°F to 122°F) |
| Operating Temperature – Communication Base | Charging: 5°C to 40°C (41°F to 104°F) Non-Charging: 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| ESD Protection | ±8 kV indirect, ±15 kV direct |
| Humidity | 0% to 95% RH, non-condensing |
| Drop Resistance | Scanner: 1.5 m (5 drops) Base: 1.0 m (2 drops) |
| Environmental Sealing | IP40 |
| Light Levels | 0 – 100,000 lux |
| SYSTEM ARCHITECTURE | |
| Operating Power (Charging) | 2.5 W (USB), 5 W (Adaptor) |
| Standby Power (Base) | 0.25 W |
| Host Interfaces | USB, HID |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Image (1040 x 720 CMOS) |
| Minimum Print Contrast | 25% |
| Motion Tolerance | 25 cm/s (for 13 mil UPC) |
| Resolution | 4 mil (1D); 6.7 mil (2D) |
| Scan Angle | Horizontal: 39.2° Vertical: 27.4° |
| Roll, Pitch, Skew | ±180°, ±65°, ±65° |
| Barcode Types | 1D, PDF, 2D, DotCode (config. dependent) |
| WIRELESS | |
| Radio/Range | 2.4 GHz to 2.5 GHz Bluetooth v5.2 30 m (98 ft) line of sight |
| Battery | 2730 mAh Li-ion |
| Number of Scans per Charge | Up to 50,000 |
| Operation Duration | 12 hours |
| Charge Time | 4 hours |
| User Indicators | LEDs, Beeper, Charge Indicator |
| WARRANTY | 3-year factory warranty |
