| Physical | |
| Dimensions (L x W x H) | 85 mm x 88 mm x 139 mm |
| Weight | 278 ±10 g |
| Electrical | |
| Input Voltage | 5 VDC ±0.5 V |
| Working Power | 2.0 W (400 mA @ 5 V) |
| Standby Power | 0.85 W (170 mA @ 5 V) |
| Host Interface | USB, RS-232 |
| Environmental | |
| Operating Temperature | -10°C to 40°C (14°F to 104°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Humidity | 0% to 95% RH, non-condensing |
| Drop | Designed to withstand 1 m drops |
| Illuminance | 0 – 100,000 Lux |
| Scanning Performance | |
| DPI | 1280 x 800 pixel |
| Motion Tolerance | Up to 2.5 m/s for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal: 47° Vertical: 30° |
| Print Contrast | 20% minimum reflectance difference |
| Pitch, Skew | ±60°, ±70° |
| Decode Capability | Reads standard 1D, PDF, 2D symbologies Note: Decode capabilities dependent on kit configuration |
| Warranty | 3-year factory warranty |
