| MECHANICAL | |
|---|---|
| Dimensions | 164 mm x 73 mm x 24.5 mm (6.5 in x 2.9 in x 1.0 in) |
| Weight | 300g (10.6 oz) with battery |
| Display | 10.6 cm (4-inch) |
| Resolution | WVGA 480 x 800 |
| Type | Transmissive |
| Backlight | LED |
| Touchscreen | Multi-touch capacitive |
| Keyboard | 26-key numeric main keypad; side keys: volume up/down, right and left scan keys; soft keys: 3 touch keys (Back, Home, Menu) |
| ENVIRONMENTAL | |
| Operating Temperature | -10°C to +50°C (14°F to 122°F) |
| Storage Temperature | -20°C to +60°C (-4°F to +148°F) |
| Humidity | 10% to 90% (non-condensing) |
| Drop | 1.5m MIL drop across operating temperature |
| ESD | ±8 kV direct; ±12 kV air |
| Environmental Sealing | IP65 |
| Vibration | Vertical rms = 1.04 g, Transverse rms = 0.2 g, Longitudinal rms = 0.74 g |
| PERFORMANCE | |
| Processor | Qualcomm 1.8 GHz octa-core |
| Memory | 3G/32G, 4G/64G Optional |
| Operating System | Android 10 with Google Mobile Services |
| Expansion Memory | MicroSDHC (up to 128 GB) |
| PC Communication | Type-C USB2.0 |
| Battery | 4000 mAh @ 3.8 V |
| Camera | 13-megapixel color camera with autofocus and LED flash |
| GPS | GNSS Receiver for GPS, GLONASS and Compass (Beidou) (for WWAN only) |
| Button Batteries | 22 mF super-cap |
| Real-Time Clock | 10-min backup via super-cap |
| Charging Time | 4 hours |
| Battery Runtime | 12 hours+ |
| Engine | 1D/2D: N6703, N3603 optional |
| LEDs | Battery Condition: Red/Green/Blue; Scan Indication: Red/Green light |
| Vibration | Vibration Motor |
| Sensors | Proximity, Light, Acceleration |
| WIRELESS CONNECTIVITY | |
| WLAN | IEEE 802.11 a/b/g/n/ac radio, Wi-Fi certified |
| WLAN Security | Open, WEP, WPA/WPA2-PSK, PEAP, EAP-TLS, EAP-TTLS, EAP-PWD, EAP-SIM, EAP-AKA |
| WWAN* | GSM & EDGE: Band 2/3/5/8 WCDMA: Band 1/2/4/5/6/8/9/19 FDD-LTE: Band 1/2/3/4/5/7/8/9/12/13/17/19/20/25/26/28/30/66 TDD-LTE: Band 38/39/40/41 (2555~2655) |
| Bluetooth | Bluetooth® Class 4.2 |
| NFC | Integrated Near Field Communication |
| ACCESSORIES (STANDARD) | |
| USB Communication Cable | Type-C USB 2.0 (PC communication, supports adapter/USB charging) |
| Wall Adapter | Included |
| ACCESSORIES (OPTIONAL) | |
| Hand Strap | Optional |
| Replacement Battery | Optional |
| Single Charging Cradle | Charges 1 terminal |
| Quad Battery Charger | Charges 4 batteries |
| USB Wall Adapter | 5V/2A |
| WARRANTY | |
| Warranty | One-year factory warranty |
