| MECHANICAL | |
|---|---|
| Dimensions | 157.6 mm × 73.8 mm × 12.15 mm (6.20 in × 2.90 in × 0.48 in) |
| Weight | 220 g (7.76 oz) |
| Display Size | 13.8 cm (5.45 in) |
| Resolution | 1440 × 720 |
| Touchscreen | 5-point touch-control, GFF |
| ENVIRONMENTAL | |
| Operating Temperature | -20°C to +60°C (–4°F to +140°F) |
| Storage Temperature | -20°C to +60°C (–4°F to +140°F) |
| Humidity | 10% to 90% (non-condensing) |
| Drop | Multiple 1.2 m (4 ft) drops to marble ground; 6 times on each side |
| Tumble | 300 times at 0.5 m (1.64 ft) |
| Environmental Sealing | IP64 |
| SYSTEM ARCHITECTURE | |
| Processor | 8-core (4 × 2.0 GHz + 4 × 1.5 GHz) |
| Memory | 2 GB RAM/16 GB Flash, 3 GB RAM/32 GB Flash |
| Operating System | Android 10 |
| Camera | 13 MP rear and 2 MP front |
| PC Interface | Type-C USB 2.0 |
| Battery | Li-Ion, 3.85 V, 4,000 mAh, built-in |
| Charging Time | 4.0 hours |
| Battery Runtime | 8.5 hours |
| Scan Engine | Honeywell N3603 (1D/2D) |
| Sensors | Acceleration, ambient light, proximity |
| Localization & Language | Worldwide English |
| WIRELESS CONNECTIVITY | |
| WLAN | IEEE 802.11 a/b/g/n/ac |
| WLAN Security | WEP, 802.1x, TKIP, AES, etc. |
| Bluetooth® | Class 5.0 |
| WWAN Radio* | GSM/EDGE: Bands 2, 3, 5, 8 UMTS/HSPA+: Bands 1, 2, 4, 5, 8, 9, 19 CDMA 1xRTT/EVDO: BC0, BC1, BC6 FDD-LTE: Bands 1, 2, 3, 4, 5, 7, 8, 9, 19, 20, 26, 28 TDD-LTE: Bands 38, 39, 40, 41 |
| NFC | Integrated Near Field Communication |
| GPS Supported Protocols | GPS, GLONASS, Galileo, BeiDou |
| ACCESSORIES (STANDARD) | |
| USB Cable | Type-C USB 2.0 (PC communication and charging) |
| Wall Adapter | 5 V/2A |
| ACCESSORIES (OPTIONAL) | |
| Hand Strap | Yes |
| Scan Handle | Yes |
| Home Base | Charges one terminal |
| WARRANTY | |
| Warranty | One-year factory warranty |
