| ELECTRICAL | |
| Input Voltage | 5.0V DC Typical |
| Operating Power | 2.5 W (500mA @ 5V) |
| Host System Interfaces | USB, RS-232, Keyboard Wedge, IBM 46xx (RS-485) |
| Auxiliary Ports | Pin Connector for future expandability |
| MECHANICAL | |
| Dimensions (L x W x H) | 80 mm x 40 mm x 105 mm, 145 mm w/ stand (3.2 in x 1.6 in x 4.1 in, 5.7 in w/ stand) |
| Weight | 340 g (12 oz) |
| Trigger | Top mounted button |
| ENVIRONMENTAL | |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 0% to 95% relative humidity, non-condensing |
| Drop | 50 drops @ 1.5 m |
| Tumble | 1,000 tumbles @ 0.5 m |
| Environmental Sealing | IP52 |
| Light Levels | 100,000 Lux |
| Beeper | 90 dB @ 10 cm |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Image (1,280 x 800 pixel array, 1MP) |
| Motion Tolerance | 400 cm/s (158 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal: 48°; Vertical: 30° |
| Print Contrast | 20% minimum reflectance difference |
| Pitch, Skew | 65°, 65° |
| Decode Capability | Reads standard 1D, 2D, PDF, Dotcode symbologies, Digimarc supported Note: Decode capabilities dependent on kit configuration. |
| TYPICAL PERFORMANCE* | |
| Performance | High performance scanning right at face of scanner (Snapdragon 801 quad-core) |
| NARROW WIDTH DEPTH OF FIELD | 3.0 mil C39 (1D): 0 – 98 mm (0 – 3.9 in) 5.0 mil C39 (1D): 0 – 151 mm (0 – 6.0 in) 10 mil DM: 0 – 129 mm (0 – 5.1 in) 13 mil UPC (1D): 0 – 250 mm (0 – 9.9 in) 6.7 mil PDF: 0 – 138 mm (0 – 5.4 in) 20 mil QR: 0 – 212 mm (0 – 8.3 in) |
