| MECHANICAL | |
| Dimensions (L x W x H) | 108 mm x 103 mm x 148 mm (4.3 in x 4.1 in x 5.8 in) |
| Weight | 410 g (14.5 oz) |
| ELECTRICAL | |
| Input Voltage | 5 VDC ± 0.25 V |
| Operating Power | 472 mA @ 5 V |
| Standby Power | 255 mA @ 5 V |
| Host System Interfaces | USB, RS-232, Keyboard Wedge, IBM468xx (RS485) |
| EAS Features | EAS with interlock and integrated RF EAS antenna (EAS model) |
| ENVIRONMENTAL | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 1.2 m (4 ft) drops |
| Environmental Sealing | Sealed to resist airborne particulate contaminants |
| Light Levels | Laser: 4842 Lux / Imager: 100,000 Lux |
| SCAN PERFORMANCE | |
| Scan Pattern | Hybrid, Omnidirectional Laser (5 fields of 4 parallel lines) and Area Imager (640 x 480 pixel array) |
| Scan Speed | Omnidirectional: 1120 scan lines per second / FPS: 30 |
| Scan Angle (Imager) | Horizontal: 40.0°, Vertical: 30.5° |
| Symbol Contrast | 35% minimum reflectance difference |
| Pitch, Skew | Laser: 60°, 60° / Imager: 60°, 70° |
| Decode Capability | Laser: Reads standard 1D, GS1 DataBar symbologies / Imager: Reads standard 1D, PDF, and 2D symbologies |
| WARRANTY | |
| Warranty | Three-year factory warranty |
