| MECHANICAL | |
| Dimensions – Scanner (L x W x H) | 192 mm x 76 mm x 100 mm (7.6 in x 3.0 in x 3.9 in) |
| Dimensions – Base (L x W x H) | 245 mm x 102 mm x 60 mm (9.6 in x 4.0 in x 2.4 in) |
| Weight – Cordless | 405 g (14.3 oz) |
| WIRELESS | |
| Radio/Range | 2.4 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth® v4.2; Class 1: 100 m (330 ft) line of sight |
| POWER OPTIONS | |
| Battery | 2450 mAh Li-ion minimum |
| Number of Scans | Up to 50,000 scans per charge |
| Expected Duration of Operation | 14 hours (1 scan per second) |
| User Indicators | Good Decode LEDs, Beeper (adjustable tone and volume), Vibration (adjustable), Bluetooth® connectivity, Battery status |
| ELECTRICAL | |
| Input Voltage | 4.0 VDC to 5.5 VDC |
| Operating Power – Cordless | 5 W (1000 mA @ 5 VDC) |
| Standby Power – Cordless | 0.6 W (120 mA @ 5 VDC) |
| Host System Interfaces | USB, Keyboard Wedge, RS-232 TTL |
| ENVIRONMENTAL | |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | Up to 95% relative humidity, non-condensing |
| Drop | 2 m (6.5 ft): 50 drops from -30°C to 50°C 2.4 m (8 ft): 20 drops at 25°C, 55% RH 3 m (10 ft): MIL-STD-810G, 25°C, 55% RH |
| Tumble | 7,000 tumbles at 1 m (3.3 ft) |
| Environmental Sealing – Scanner | IP67 and IP65 |
| Environmental Sealing – Charge/Communication Base | IP51 |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) |
| ESD | ±20 kV air discharge, ±8 kV contact discharge |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Imager (1280 x 800 pixel array) |
| Motion Tolerance | Up to 4500 mm/s (177 in/s) |
| Scan Angle | Horizontal: 40°, Vertical: 30° |
| Print Contrast | 20% minimum reflectance difference |
| Roll, Pitch, Skew | -360°, 45°, 65° |
| Decode Capabilities | Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code and OCR symbologies |
| WARRANTY | |
| Scanner | Three-year factory warranty |
| Battery Pack | One-year factory warranty |
