| WIRELESS | |
| Radio/Range | 2.4GHz Bluetooth radio v4.2 with Adaptive Frequency Hopping. Class 1: 100 m line of sight (default), programmable to Class 2: 10 m line of sight |
| Battery | 2400 mAh Li-ion minimum |
| Number of Scans | Up to 65,000 scans per charge |
| Expected Duration of Operation | 18 hours |
| Expected Charge Time | 4.5 hours |
| User Indicators | Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (adjustable), Charge Status Indicator |
| MECHANICAL/ELECTRICAL | |
| Dimensions (L x W x H) | Scanner: 104.1 mm x 71.1 mm x 160 mm (4.1 in x 2.8 in x 6.3 in) Presentation Base: 132 mm x 101 mm x 81 mm (5.2 in x 4.0 in x 3.2 in) Desktop/Wall Mount Base: 231 mm x 89 mm x 83 mm (9.1 in x 3.5 in x 3.3 in) |
| Weight | Scanner: 212.62 g (7.5 oz) Presentation Base: 179 g (6.3 oz) Desktop/Wall Mount Base: 260 g (9.2 oz) |
| Operating Power (Charging) Bases | 2.5 W (500 mA @ 5V DC) |
| Non-Charging Power (Bases) | 0.75 W (150 mA @ 5V DC) |
| Host System Interfaces | USB, Keyboard Wedge, RS-232, IBM 46xx (RS485) |
| ENVIRONMENTAL | |
| Operating Temperature | Scanner: 0°C to 50°C (32°F to 122°F) Bases Charging: 5°C to 40°C (41°F to 104°F), Non-Charging: 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Electrostatic Discharge (ESD) | ±8 kV indirect coupling plane, ±15 kV direct air |
| Humidity | 0 to 95% relative humidity, non-condensing |
| Tumble Spec | 2,000 0.5 m (1.6 ft) tumbles (impacts) |
| Drop | Engineered to withstand 50 1.8 m (6 ft) drops to concrete |
| Environmental Sealing (Scanner) | IP52 |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) |
| SCAN PERFORMANCE | |
| Scan Pattern | Area Image (1280 x 800 pixel array) |
| Motion Tolerance | Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | SR: Horizontal: 42° ; Vertical: 27° HD: Horizontal: 42° ; Vertical: 27° UD: Horizontal: 40° ; Vertical: 26° |
| Print Contrast | 20% minimum reflectance difference |
| Roll, Pitch, Skew | ±360°, ±45°, ±65° |
| Decode Capabilities | Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code, and OCR symbologies (Note: Decode capabilities dependent on configuration.) *Xenon XP 1952g UV: Built to detect UV watermarks embedded in 1D and 2D barcodes |
| WARRANTY | |
| Warranty | Three-year factory warranty |
