| MECHANICAL / ELECTRICAL | ||
| Dimensions (L x W x H) | 99 mm x 64 mm x 165 mm (3.9 in x 2.5 in x 6.5 in) | |
| Scanner Weight | 160 g (5.6 oz) | |
| Input Voltage | 4.4V DC – 5.5V DC | |
| Operating Power (Charging) Bases | 2.5 W (500 mA @ 5V DC) | |
| Host System Interfaces | USB, Keyboard Wedge, RS-232, RS485 support for TGCS (IBM) 46XX | |
| User Indicators | Good Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume), Vibration (optional) | |
| ENVIRONMENTAL | ||
| Operating Temperature | 0°C to 50°C (32°F to 122°F) | |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) | |
| Electrostatic Discharge (ESD) | ±8 kV indirect coupling plane, ±15 kV direct air | |
| Humidity | 0% to 95% relative humidity, non-condensing | |
| Tumble Spec | 2,000 tumbles at 0.5 m (1.6 ft) | |
| Drop | Engineered to withstand 50 drops from 1.8 m (6 ft) to concrete | |
| Environmental Sealing | IP52 | |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) | |
| SCAN PERFORMANCE & WARRANTY | ||
| Scan Pattern | Area Image (1280 x 800 pixel array) | |
| Motion Tolerance | Up to 400 cm/s (157 in/s) for 13 mil UPC at optimal focus | |
| Scan Angle | SR: Horizontal 48°, Vertical 30° HD: Horizontal 48°, Vertical 30° |
|
| Print Contrast | 20% minimum reflectance difference | |
| Roll, Pitch, Skew | ±360°, ±45°, ±65° | |
| Decode Capabilities | Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code, and OCR symbologies Note: Decode capabilities dependent on configuration |
|
| Warranty | 5-year factory warranty | |
