Wireless Connectivity |
Radio / Range |
2.4 to 2.5 GHz (ISM Band), Adaptive Frequency Hopping, Bluetooth v2.1; Class 2; 10 m (33 ft) line of sight |
Battery |
750 mAh Li-ion minimum |
Number of Scans |
Up to 2,250 scans per full charge |
Expected Hours of Operation |
12 hours |
Expected Charge Time |
3 hours |
Mechanical / Electrical |
Dimensions (L x W x H) |
120 x 48 x 22 mm (4.7 x 1.9 x 0.9 in) |
Weight |
< 100 g (3.5 oz) |
Environmental |
Operating Temperature |
0°C to 50°C (32°F to 122°F) |
While Charging |
0°C to 40°C (32°F to 104°F) |
Humidity |
0% to 95% relative humidity, non-condensing |
Drop |
Designed to withstand 30 drops from 1.4 m (4 ft) to concrete |
Environmental Sealing |
IP52 |
Light Levels |
0 to 100,000 lux (9,290 foot-candles) |
Scan Performance & Warranty |
Scan Pattern |
Area Image (1040 x 720 pixel array) |
Motion Tolerance |
Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus |
Scan Angle |
Horizontal: 41.4°; Vertical: 32.2° |
Symbol Contrast |
35% minimum reflectance difference |
Warranty |
3-year factory warranty |
