| Mechanical / Electrical | |
| Dimensions (L x W x H) | 62 mm x 169 mm x 82 mm (2.4 in x 6.6 in x 3.2 in) |
| Scanner Weight | 130 g (4.6 oz) |
| Input Voltage | 4.0V DC to 5.5V DC |
| Operating Power | 2 W (400 mA @ 5V DC) |
| Standby Power | 0.45 W (90 mA @ 5V DC) |
| Host System Interfaces | USB, Keyboard Wedge, RS-232, RS485 support for IBM 46xx (RS485) |
| Environmental | |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Electrostatic Discharge (ESD) | ±8 kV indirect coupling plane, ±15 kV direct air |
| Humidity | 0% to 95% relative humidity, non-condensing |
| Tumble Spec | 1,000 tumbles at 0.5 m (1.6 ft) |
| Drop | Engineered to withstand 30 drops from 1.8 m (6 ft) to concrete |
| Environmental Sealing | IP40 |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) |
| Scan Performance & Warranty | |
| Scan Pattern | Area Image (1040 x 720 pixel array) |
| Motion Tolerance | 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal: 39.2° nominal; Vertical: 27.4° nominal |
| Roll, Pitch, Skew | ±180°, ±65°, ±70° |
| Decode Capabilities | Reads standard 1D, PDF, 2D, and DotCode symbologies Note: Decode capabilities dependent on configuration. |
| Warranty | 5-year factory warranty |
