| Mechanical / Electrical | |
| Dimensions | 150 mm x 112 mm x 79 mm (5.9 ̋ x 4.4 ̋ x 3.1 ̋) |
| Weight | 160 g (5.6 oz) |
| Input Voltage | 5V ± 5% |
| Operating Power | 1000 mW; 200 mA (typical) @ 5V |
| Standby Power | 625 mW; 125 mA (typical) @ 5V |
| Host System Interfaces | Multi-Interface / includes RS232 (TTL +5V, 4 Signals) / KBW / USB (HID keyboard, serial, IBM OEM); RS-232C (±12V) and IBM RS485 supported via adapter cable |
| Auxiliary Ports | N/A |
| Environmental | |
| Operating Temperature | 0°C – 50°C (32°F to 122°F) |
| Storage Temperature | -40°C – 60°C (-40°F to 140°F) |
| Humidity | 0 to 95% non-condensing |
| Drop / Tumble | Designed to withstand 50 drops on concrete from 1.5 m |
| Environmental Sealing | IP41 |
| Light Levels | 0 – 70,000 lux (direct sunlight) |
| Scan Performance & Warranty | |
| Scan Pattern | Single line |
| Motion Tolerance | 20 in (51 cm) per second |
| Scan Rate | Up to 270 scans per second |
| Print Contrast | 20% minimum reflectance difference |
| Pitch, Skew | 65°, 65° |
| Decode Capabilities | Reads standard 1D and GS1 DataBar™ symbologies |
| Warranty | 5 year factory warranty |
