| Mechanical | |
| Dimensions (LxWxH) | 60 mm x 168 mm x 74 mm (2.3 ̋ x 6.6 ̋ x 2.9 ̋) |
| Weight | 133 g (4.7 oz) |
| Electrical | |
| Input Voltage | 5 V ± 5% |
| Operating Power | 700 mW; 140 mA (typical) @ 5V |
| Standby Power | 425 mW; 85 mA (typical) @ 5V |
| Host System Interfaces | Multi-interface; includes USB (HID Keyboard, Serial, IBM OEM), RS232 (TTL +5V, 4 signals), Keyboard Wedge, RS-232C (±12V), IBM RS485 supported via adapter cable |
| Environmental | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 30 drops on concrete from 1.5 m (5’) |
| Environmental Sealing | IP41 |
| Light Levels | 0-75,000 Lux (direct sunlight) |
| Scan Performance & Warranty | |
| Scan Pattern | Single scan line |
| Scan Angle | Horizontal: 30° |
| Print Contrast | 20% minimum reflectance difference |
| Pitch, Skew | 60°, 60° |
| Decode Capabilities | Reads standard 1D and GS1 DataBar symbologies |
| Warranty | 5 year factory warranty |
