| Mechanical | |
| Dimensions (LxWxH) | 66 mm x 180 mm x 97 mm |
| Weight | 125 g |
| Electrical | |
| Input Voltage | 5 V ± 5% |
| Operating Power | 700 mW; 140 mA (typical) @ 5V |
| Standby Power | 350 mW; 70 mA (typical) @ 5V |
| Host System Interfaces | Multi-Interface (RS232 TTL +5V, 4 Signals) / KBW / USB (HID Keyboard, Serial, IBM OEM); RS-232C (+/-12V) and IBM RS485 supported via adapter cable |
| Environmental | |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 0% to 95% non-condensing |
| Drop Resistance | Designed to withstand 30 drops from 1.5 m onto concrete |
| Environmental Sealing | IP42 |
| Light Levels | 0 – 100,000 lux (direct sunlight) |
| Scan Performance & Warranty | |
| Scan Pattern | Single scan line |
| Scan Angle | Horizontal: 30° |
| Print Contrast | 10% minimum reflectance difference |
| Pitch / Skew | 60°, 60° |
| Decode Capabilities | Reads standard 1D and GS1 DataBar symbologies |
| Factory Warranty | 5 years |
