| Enterprise Testing Conditions |
|---|
| Threat Prevention (Gbps)1 | 1.5 |
| NGFW2 (Gbps) | 3 |
| IPS Throughput (Gbps) | 3.3 |
| Firewall Throughput (Gbps) | 3.6 |
| RFC 3511, 2544, 2647, 1242 Performance (LAB) |
|---|
| Firewall 1518B UDP (Gbps) | 4 |
| VPN AES-128 (Gbps) | 2.75 |
| Connections per Second | 60,000 |
| Concurennt Connections | 4M |
| Additional Features |
|---|
| Highlights | - 1x CPUs, 8 physical cores
- 1x 240 GB SSD storage
- 16 GB memory
- Virtual Systems (maximum): 10
|
| Content Security |
|---|
| First Time Prevention Capabilities | - CPU-level, OS-level and static file analysis
- File disarm and reconstruction via Threat Extraction
- Average emulation time for unknown files that require full sandbox evaluation is under 100 seconds
- Maximal file size for Emulation is 100 MB
- Emulation OS Support: Windows XP, 7, 8.1, 10
|
| Applications | - Use 8,000+ pre-defined or customize your own applications
- Accept, prevent, schedule, and apply traffic-shaping
|
| Data Loss Prevention | - Classify 700+ pre-defined data types
- End user and data owner incident handling
|
| Dynamic User-based Policy | - Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid, Terminal Servers and with 3rd parties via a Web API
- Enforce consistent policy for local and remote users on Windows, macOS, Linux, Android and Apple iOS platforms
|
| Network |
|---|
| Network Connectivity | - Total physical and virtual (VLAN) interfaces per appliance: 1024/4096 (single gateway/with virtual systems)
- 802.3ad passive and active link aggregation
- Layer 2 (transparent) and Layer 3 (routing) mode
|
| High Availability | - Active/Active L2, Active/Passive L2 and L3
- Session failover for routing change, device and link failure
- ClusterXL or VRRP
|
| IPv6 | - NAT66, NAT64, NAT46
- CoreXL, SecureXL, HA with VRRPv3
|
| Unicast and Multicast Routing (see SK98226) | - OSPFv2 and v3, BGP, RIP
- Static routes, Multicast routes
- Policy-based routing
- PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3
|
| Power Requirements |
|---|
| Single Power Supply rating | 40W |
| AC power input | 100 to 240V (50-60Hz) |
| Power consumption max | 24.2W |
| Maximum thermal output | 82.6 BTU/hr. |
| Dimensions |
|---|
| Enclosure | Desktop |
| Dimensions (WxDxH) | 8.3 x 8.3 x 1.65 in. (210 x 210 x 42mm) |
| Weight | 3.1 lbs. (1.4 kg) |
| Environmental Conditions |
|---|
| Operating | 0° to 40°C, humidity 95% |
| Storage | –20° to 70°C, humidity 95% |
| Certifications |
|---|
| Safety | UL, CB, CE, TUV GS |
| Emissions | FCC, CE, VCCI, RCM/C-Tick |
| Environmental | RoHS, WEEE, REACH, ISO14001 |
